Casement-Window-109-Series

Product Detail

Floot Drain Drainage

Our advanced floor drain drainage system offers superior safety protection with no dripping. It efficiently removes rainwater, prevents backflow, and ensures reliable performance even in low-light conditions.

Flush Inside and Outside

The interior and exterior flush design offers a modern aesthetic with clean, strong lines. This design creates a neat, flat, and generous appearance, providing a clear and cohesive window texture that enhances the overall visual appeal.

Hardware

Handle

Screen Sash Hinge

Glass Sash Hinge

Casement Window Aluminum丨109 Series

Specifications

Aluminum Profile Thickness 1.4mm
Frame Dimensions Width: 109mm, Thickness: 30mm
Glass Configuration 5mm + 20A + 5mm Xinyi Glass
Hardware Well-known Brand Hardware
Opening Method Casement

Colour

Outside Color

Inner Color

Fluorocarbon Gray
Fluorocarbon Coffee
Fluorocarbon Gray
Fluorocarbon Coffee

Outside Color

Fluorocarbon Gray
Fluorocarbon Coffee

Inner Color

Fluorocarbon Gray
Fluorocarbon Coffee
  • Material: Made from primary aluminum 6063-T5.
  • Surface Treatment: Uses fluorocarbon process treatment and imported metallic powder coating technology for a more refined surface, improved weather resistance, and corrosion resistance.
  • Insulation Strips: Uses PA66GF25 material (Nylon 66 with 25% glass fiber) for better thermal insulation.
  • Sealing Strips: Made of EPDM rubber, providing excellent corrosion resistance and preventing hardening.
  • Concealed Drainage: Ensures smooth water drainage, preventing water accumulation and backflow.
  • Flush Frame and Sash Design: Enhances the aesthetic appeal and improves waterproofing and sealingperformance.
  • Safety Mesh: Equipped with 3048mm stainless steel mesh for durability and safety.
  • Interior Screen Corner Design: Uses metal R chamfer corners to effectively prevent injury from collisions.
  • Anti-Fall Chain: Unique design to prevent accidental falling of the window sash, providing greater safety.
  • Injected Corner Brackets: The outer frame uses injected corner brackets for a stronger and more sealed structure.

Thermal Insulation

Grade

6

Sound Insulation

Grade

8

Water Tightness

Grade

6

Air Tightness

Grade

7

Wind Pressure Resistance

Grade

7
